tactile Back Light Membrane Switch with water-proof and LGF design
Applications of Backlit Membrane Switches
Lunfeng's custom-designed membrane switches and membrane switch keypads. Membrane switches are used in many industries. Niceone-tech summarizes several best membrane switch industries:
Medical Equipment and laboratories are the major markets. Lunfeng provides customized membrane switches with complex requirements for many European and American manufacturers. In the medical environment, based on the standard membrane keypad, the materials sometimes have antibacterial effects and easy cleaning characteristics. At the same time Niceone-tech applies backlit and glue technology to the membrane switch. It can even be produced using digital printing.
Industrial Controls: Because industrial equipment is more demanding moisture resistance and UV resistance, so the product's waterproof requirements and UV resistance performance requirements are relatively high. The choice of materials can refer to the membrane switch design guide (to change into go This page), I believe that the materials compiled by Niceone-tech can help you.
Health & Fitness Equipment: Because it is often corroded by sweat, salt and moisture, the material must be resistant to corrosion. Membrane switches are often used in treadmills. Using membrane switches to optimize performance and control is very important for fitness personnel
Advantages of LGF Lighting
LGF lights are available in almost any shape. Their versatility and flexibility make them the top choice for backlit switches.
LGF membrane switch is very useful for compact and thin devices.
It ensures minimal to almost no impact on the tactility of the switch buttons of the membrane.
With LGF switch, you can enjoy uniform lighting across one or more areas within a switch.
Our Advantage:
We Focus in membrane switch and related items.
Strong R&D capability
Stable in quality
Competitive price
Short Lead time for samples and Mass production
Whole solution design available
Applications:
* home appliances and device
* Security Protection systems with Cipher Code
* Various industry control keypad panel
* consumer electronics and 3C item
* Thrapy medical system and device
Various automtic machine control keypad
| Items | Silver Printed Circuit | Copper Etched FPC Circuit |
| Material | PET (Polyester) | Copper |
| Conductor | Printed silver | Copper |
| Contact Fingers | Silver and Carbon | Gold plated |
| Contact Buttons Pads | Silver | Gold plated |
| Life & Reliability | normal | good |
| Stability | normal | good |
| Resistance | low | Very low |
| Cost | low | high |
| Lead Time | 2-3 days | 7-10 days |
| Pitch | 0.5mm (not suggested), 1.0mm, 1.27mm, 2.54mm | 0.5mm, 1.0mm, 1.27mm, 2.54mm
|
| 1.Electrical Properties | Membrane Switch |
| Electrical Level: | 35V(DC), 100mA,1W |
| Contact Resistance: | 10Ω~500 Ω |
| Insulation Resistance: | 100MΩ/100V |
| Dielectrics Voltage-resistance: | 250VRms(50~60Hz 1min) |
| Chattering Time: | ≤ 5ms |
| Life Time: | Flat type ≥ 5,000,000; Tactile type ≥ 1,000,000 |
| Tail Folding: | R>1,180 |
| | |
| 2.Mechanical Properties | |
| Operating Force: | Flat type 57~284g (2~10oz); Tactile type 170~397g(6~14oz) |
| Switch Stroke: | Flat type 0.1~0.5mm; Tactile type 0.6~1.5mm |
| | |
| 3.Environmental and Storage Conditions | |
| Operation Temperature: | -40°C ~ +80°C |
| Storage Temperature: | -40°C ~ +80°C |
| Humidity: | 40°C, 90%~95%, 240 hours
|
